Freelin Wade

1/2" OD Freelin-Wade Free-Thane 95A Tubing

FRE-THANE 95A durometer polyurethane tubing is compatible with most brands of push-to-connect pneumatic fittings and is a very popular choice for general-purpose flexible pneumatic lines.
  • Extremely Flexible—Small bend radius for routing into tight places.
  • Very Kink Resistant—Withstands abuse that would damage other plastic tubings.
  • Excellent Memory—Tolerates repeated flexing.
  • Very Abrasion Resistant—Outlasts other tubings, suitable for conveying abrasives.
  • Broad Resistances—To chemicals, water, fuel, oil and fungus.
  • Temperature Range—240°F to +165°F
  • Vacuum Rating—To 28” Hg.

Part Number
Package Length
OKCancelClear All
Color
O.D.
I.D.
Wall
Working Pressure @ 75F
Working Pressure @ 150F
Bend Radius
Fitting Type
1J-166-01
50 ft.
Black
1/2"
.320"
.090"
175 PSI
70 PSI
1-1/8"
Barb & Push-in
1A-166-01
250 ft.
Black
1/2"
.320"
.090"
175 PSI
70 PSI
1-1/8"
Barb & Push-in
Part Number
Package Length
OKCancelClear All
Color
O.D.
I.D.
Wall
Working Pressure @ 75F
Working Pressure @ 150F
Bend Radius
Fitting Type
1J-166-07
50 ft.
Blue
1/2"
.320"
.090"
175 PSI
70 PSI
1-1/8"
Barb & Push-in
1A-166-07
250 ft.
Blue
1/2"
.320"
.090"
175 PSI
70 PSI
1-1/8"
Barb & Push-in
Part Number
Package Length
OKCancelClear All
Color
O.D.
I.D.
Wall
Working Pressure @ 75F
Working Pressure @ 150F
Bend Radius
Fitting Type
1J-166-10
50 ft.
Clear
1/2"
.320"
.090"
175 PSI
70 PSI
1-1/8"
Barb & Push-in
1A-166-10
250 ft.
Clear
1/2"
.320"
.090"
175 PSI
70 PSI
1-1/8"
Barb & Push-in
Part Number
Package Length
Color
O.D.
I.D.
Wall
Working Pressure @ 75F
Working Pressure @ 150F
Bend Radius
Fitting Type
1J-166-06
50 ft.
Green
1/2"
.320"
.090"
175 PSI
70 PSI
1-1/8"
Barb & Push-in
Part Number
Package Length
Color
O.D.
I.D.
Wall
Working Pressure @ 75F
Working Pressure @ 150F
Bend Radius
Fitting Type
1J-166-06
50 ft.
Green
1/2"
.320"
.090"
175 PSI
70 PSI
1-1/8"
Barb & Push-in
Part Number
Package Length
OKCancelClear All
Color
O.D.
I.D.
Wall
Working Pressure @ 75F
Working Pressure @ 150F
Bend Radius
Fitting Type
1J-166-27
50 ft.
Trans. Blue
1/2"
.320"
.090"
175 PSI
70 PSI
1-1/8"
Barb & Push-in
1A-166-27
250 ft.
Trans. Blue
1/2"
.320"
.090"
175 PSI
70 PSI
1-1/8"
Barb & Push-in
Part Number
Package Length
OKCancelClear All
Color
O.D.
I.D.
Wall
Working Pressure @ 75F
Working Pressure @ 150F
Bend Radius
Fitting Type
1J-166-05
50 ft.
Red
1/2"
.320"
.090"
175 PSI
70 PSI
1-1/8"
Barb & Push-in
1A-166-05
250 ft.
Red
1/2"
.320"
.090"
175 PSI
70 PSI
1-1/8"
Barb & Push-in
Part Number
Package Length
OKCancelClear All
Color
O.D.
I.D.
Wall
Working Pressure @ 75F
Working Pressure @ 150F
Bend Radius
Fitting Type
1J-166-37
50 ft.
Ice Blue
1/2"
.320"
.090"
175 PSI
70 PSI
1-1/8"
Barb & Push-in
1A-166-37
250 ft.
Ice Blue
1/2"
.320"
.090"
175 PSI
70 PSI
1-1/8"
Barb & Push-in
Part Number
Package Length
OKCancelClear All
Color
O.D.
I.D.
Wall
Working Pressure @ 75F
Working Pressure @ 150F
Bend Radius
Fitting Type
1J-166-08
50 ft.
Yellow
1/2"
.320"
.090"
175 PSI
70 PSI
1-1/8"
Barb & Push-in
1A-166-08
250 ft.
Yellow
1/2"
.320"
.090"
175 PSI
70 PSI
1-1/8"
Barb & Push-in
