NOSHOK

200 Series Low Pressure Diaphragm Gauges

The NOSHOK 200 Series offers economical, reliable performance in a compact design—ideal for general-purpose pressure measurement. These glycerine-filled gauges feature a rugged stainless steel case and brass internals, providing excellent resistance to vibration, shock, and pulsation. With easy-to-read UV-resistant dials, a polycarbonate lens, and multiple mounting and connection options, the 200 Series is a trusted choice for a wide range of non-corrosive applications.

Part Number
Pressure Range
OKCancelClear All
Dial Size
OKCancelClear All
Case Material
OKCancelClear All
Mount
Connection
Type
Accuracy
Scale
25-200-30IN/H2O/VAC
0–30" H2O Vac
2½″
Steel
Bottom
¼″ NPT
Dry Pressure Gauge
±1.5% Full Scale
Dual Scale PSI/in. H₂O
25-200-60IN/H2O/VAC
0–60" H2O Vac
2½″
Steel
Bottom
¼″ NPT
Dry Pressure Gauge
±1.5% Full Scale
Dual Scale PSI/in. H₂O
25-200-100IN/H2O/VAC
0–100" H2O Vac
2½″
Steel
Bottom
¼″ NPT
Dry Pressure Gauge
±1.5% Full Scale
Dual Scale PSI/in. H₂O
25-200-15IN/H2O
0–15" H2O
2½″
Steel
Bottom
¼″ NPT
Dry Pressure Gauge
±1.5% Full Scale
Dual Scale PSI/in. H₂O
25-200-30IN/H2O
0–30" H2O
2½″
Steel
Bottom
¼″ NPT
Dry Pressure Gauge
±1.5% Full Scale
Dual Scale PSI/in. H₂O
25-200-60IN/H2O
0–60" H2O
2½″
Steel
Bottom
¼″ NPT
Dry Pressure Gauge
±1.5% Full Scale
Dual Scale PSI/in. H₂O
25-200-100IN/H2O
0–100" H2O
2½″
Steel
Bottom
¼″ NPT
Dry Pressure Gauge
±1.5% Full Scale
Dual Scale PSI/in. H₂O
25-200-200IN/H2O
0–200" H2O
2½″
Steel
Bottom
¼″ NPT
Dry Pressure Gauge
±1.5% Full Scale
Dual Scale PSI/in. H₂O
25-200-3
0–3 PSI
2½″
Steel
Bottom
¼″ NPT
Dry Pressure Gauge
±1.5% Full Scale
Dual Scale PSI/in. H₂O
25-200-5
0–5 PSI
2½″
Steel
Bottom
¼″ NPT
Dry Pressure Gauge
±1.5% Full Scale
Dual Scale PSI/in. H₂O
25-200-10
0–10 PSI
2½″
Steel
Bottom
¼″ NPT
Dry Pressure Gauge
±1.5% Full Scale
Dual Scale PSI/in. H₂O
40-200-30IN/H2O/VAC
0–30" H2O Vac
4″
Stainless Steel
Bottom
¼″ NPT
Dry Pressure Gauge
±1.5% Full Scale
Dual Scale PSI/in. H₂O
40-200-60IN/H2O/VAC
0–60" H2O Vac
4″
Stainless Steel
Bottom
¼″ NPT
Dry Pressure Gauge
±1.5% Full Scale
Dual Scale PSI/in. H₂O
40-200-100IN/H2O/VAC
0–100" H2O Vac
4″
Stainless Steel
Bottom
¼″ NPT
Dry Pressure Gauge
±1.5% Full Scale
Dual Scale PSI/in. H₂O
40-200-15IN/H2O
0–15" H2O
4″
Stainless Steel
Bottom
¼″ NPT
Dry Pressure Gauge
±1.5% Full Scale
Dual Scale PSI/in. H₂O
40-200-30IN/H2O
0–30" H2O
4″
Stainless Steel
Bottom
¼″ NPT
Dry Pressure Gauge
±1.5% Full Scale
Dual Scale PSI/in. H₂O
40-200-60IN/H2O
0–60" H2O
4″
Stainless Steel
Bottom
¼″ NPT
Dry Pressure Gauge
±1.5% Full Scale
Dual Scale PSI/in. H₂O
40-200-100IN/H2O
0–100" H2O
4″
Stainless Steel
Bottom
¼″ NPT
Dry Pressure Gauge
±1.5% Full Scale
Dual Scale PSI/in. H₂O
40-200-200IN/H2O
0–200" H2O
4″
Stainless Steel
Bottom
¼″ NPT
Dry Pressure Gauge
±1.5% Full Scale
Dual Scale PSI/in. H₂O
40-200-3*
0–3 PSI
4″
Stainless Steel
Bottom
¼″ NPT
Dry Pressure Gauge
±1.5% Full Scale
Dual Scale PSI/in. H₂O
40-200-5
0–5 PSI
4″
Stainless Steel
Bottom
¼″ NPT
Dry Pressure Gauge
±1.5% Full Scale
Dual Scale PSI/in. H₂O
40-200-10
0–10 PSI
4″
Stainless Steel
Bottom
¼″ NPT
Dry Pressure Gauge
±1.5% Full Scale
Dual Scale PSI/in. H₂O
Part Number
Pressure Range
OKCancelClear All
Dial Size
OKCancelClear All
Case Material
OKCancelClear All
Mount
OKCancelClear All
Connection
Type
Accuracy
Scale
25-200-30IN/H2O/VAC
0–30" H2O Vac
2½″
Steel
Bottom
¼″ NPT
Dry Pressure Gauge
±1.5% Full Scale
Dual Scale PSI/in. H₂O
25-200-60IN/H2O/VAC
0–60" H2O Vac
2½″
Steel
Bottom
¼″ NPT
Dry Pressure Gauge
±1.5% Full Scale
Dual Scale PSI/in. H₂O
25-200-100IN/H2O/VAC
0–100" H2O Vac
2½″
Steel
Bottom
¼″ NPT
Dry Pressure Gauge
±1.5% Full Scale
Dual Scale PSI/in. H₂O
25-200-15IN/H2O
0–15" H2O
2½″
Steel
Bottom
¼″ NPT
Dry Pressure Gauge
±1.5% Full Scale
Dual Scale PSI/in. H₂O
25-200-30IN/H2O
0–30" H2O
2½″
Steel
Bottom
¼″ NPT
Dry Pressure Gauge
±1.5% Full Scale
Dual Scale PSI/in. H₂O
25-200-60IN/H2O
0–60" H2O
2½″
Steel
Bottom
¼″ NPT
Dry Pressure Gauge
±1.5% Full Scale
Dual Scale PSI/in. H₂O
25-200-100IN/H2O
0–100" H2O
2½″
Steel
Bottom
¼″ NPT
Dry Pressure Gauge
±1.5% Full Scale
Dual Scale PSI/in. H₂O
25-200-200IN/H2O
0–200" H2O
2½″
Steel
Bottom
¼″ NPT
Dry Pressure Gauge
±1.5% Full Scale
Dual Scale PSI/in. H₂O
25-200-3
0–3 PSI
2½″
Steel
Bottom
¼″ NPT
Dry Pressure Gauge
±1.5% Full Scale
Dual Scale PSI/in. H₂O
25-200-5
0–5 PSI
2½″
Steel
Bottom
¼″ NPT
Dry Pressure Gauge
±1.5% Full Scale
Dual Scale PSI/in. H₂O
25-200-10
0–10 PSI
2½″
Steel
Bottom
¼″ NPT
Dry Pressure Gauge
±1.5% Full Scale
Dual Scale PSI/in. H₂O
25-210-30IN/H2O/VAC
0–30" H2O Vac
2½″
Steel
Back
¼″ NPT
Dry Pressure Gauge
±1.5% Full Scale
Dual Scale PSI/in. H₂O
25-210-60IN/H2O/VAC
0–60" H2O Vac
2½″
Steel
Back
¼″ NPT
Dry Pressure Gauge
±1.5% Full Scale
Dual Scale PSI/in. H₂O
25-210-100IN/H2O/VAC
0–100" H2O Vac
2½″
Steel
Back
¼″ NPT
Dry Pressure Gauge
±1.5% Full Scale
Dual Scale PSI/in. H₂O
25-210-15IN/H2O
0–15" H2O
2½″
Steel
Back
¼″ NPT
Dry Pressure Gauge
±1.5% Full Scale
Dual Scale PSI/in. H₂O
25-210-30IN/H2O
0–30" H2O
2½″
Steel
Back
¼″ NPT
Dry Pressure Gauge
±1.5% Full Scale
Dual Scale PSI/in. H₂O
25-210-60IN/H2O
0–60" H2O
2½″
Steel
Back
¼″ NPT
Dry Pressure Gauge
±1.5% Full Scale
Dual Scale PSI/in. H₂O
25-210-100IN/H2O
0–100" H2O
2½″
Steel
Back
¼″ NPT
Dry Pressure Gauge
±1.5% Full Scale
Dual Scale PSI/in. H₂O
25-210-200IN/H2O
0–200" H2O
2½″
Steel
Back
¼″ NPT
Dry Pressure Gauge
±1.5% Full Scale
Dual Scale PSI/in. H₂O
25-210-3*
0–3 PSI
2½″
Steel
Back
¼″ NPT
Dry Pressure Gauge
±1.5% Full Scale
Dual Scale PSI/in. H₂O
25-210-5
0–5 PSI
2½″
Steel
Back
¼″ NPT
Dry Pressure Gauge
±1.5% Full Scale
Dual Scale PSI/in. H₂O
25-210-10
0–10 PSI
2½″
Steel
Back
¼″ NPT
Dry Pressure Gauge
±1.5% Full Scale
Dual Scale PSI/in. H₂O
40-200-30IN/H2O/VAC
0–30" H2O Vac
4″
Stainless Steel
Bottom
¼″ NPT
Dry Pressure Gauge
±1.5% Full Scale
Dual Scale PSI/in. H₂O
40-200-60IN/H2O/VAC
0–60" H2O Vac
4″
Stainless Steel
Bottom
¼″ NPT
Dry Pressure Gauge
±1.5% Full Scale
Dual Scale PSI/in. H₂O
40-200-100IN/H2O/VAC
0–100" H2O Vac
4″
Stainless Steel
Bottom
¼″ NPT
Dry Pressure Gauge
±1.5% Full Scale
Dual Scale PSI/in. H₂O
40-200-15IN/H2O
0–15" H2O
4″
Stainless Steel
Bottom
¼″ NPT
Dry Pressure Gauge
±1.5% Full Scale
Dual Scale PSI/in. H₂O
40-200-30IN/H2O
0–30" H2O
4″
Stainless Steel
Bottom
¼″ NPT
Dry Pressure Gauge
±1.5% Full Scale
Dual Scale PSI/in. H₂O
40-200-60IN/H2O
0–60" H2O
4″
Stainless Steel
Bottom
¼″ NPT
Dry Pressure Gauge
±1.5% Full Scale
Dual Scale PSI/in. H₂O
40-200-100IN/H2O
0–100" H2O
4″
Stainless Steel
Bottom
¼″ NPT
Dry Pressure Gauge
±1.5% Full Scale
Dual Scale PSI/in. H₂O
40-200-200IN/H2O
0–200" H2O
4″
Stainless Steel
Bottom
¼″ NPT
Dry Pressure Gauge
±1.5% Full Scale
Dual Scale PSI/in. H₂O
40-200-3*
0–3 PSI
4″
Stainless Steel
Bottom
¼″ NPT
Dry Pressure Gauge
±1.5% Full Scale
Dual Scale PSI/in. H₂O
40-200-5
0–5 PSI
4″
Stainless Steel
Bottom
¼″ NPT
Dry Pressure Gauge
±1.5% Full Scale
Dual Scale PSI/in. H₂O
40-200-10
0–10 PSI
4″
Stainless Steel
Bottom
¼″ NPT
Dry Pressure Gauge
±1.5% Full Scale
Dual Scale PSI/in. H₂O
