Foster 3-Way Sleeve Valves

• Provides low cost ON-OFF-EXHAUST operation.
• Slide the sleeve to the ON position. Exhaust ports are closed, valve is open. Reversing the sleeve, opens exhaust ports, shuts off flow.
• Ports covered for protection against exhaust flow.
• Patented body detent secures sleeve ON position.
• Operating pressure to 200 PSI—25° to +200° F.

Part Number
Air Flow CFM, 10 PSI Pressure Drop, 100 PSIG
OKCancelClear All
Air Flow CFM, 10 PSI Pressure Drop, 80 PSIG
OKCancelClear All
Snap Ring
OKCancelClear All
Sleeve O-Ring
OKCancelClear All
Body O-Ring
OKCancelClear All
3W125
1/8 NPT
16
14.5
5103-430
111 (2 Req'd)
3W250
1/4 NPT
40
36.5
5103-560
113 (2 Req'd)
3W375
3/8 NPT
65
59.5
5103-680
115 (2 Req'd)
3W500
1/2 NPT
140
127.5
5103-100
120 (2 Req'd)
LO250
1/4 NPT
40
36.5
5103-560
113 (2 Req'd)
LO375
3/8 NPT
65
59.5
5103-680
115 (2 Req'd)
LO500
1/2 NPT
140
127.5
5103-100
120 (2 Req'd)

For 5 PSI-PD Multiply x .75 *2 Required

https://catalogs.jhf.com/Pneumatic-and-Hydraulic-Equipment/468/



REUSABLE HOSE FITTINGS AND 3-WAY VALVE

FEMALE SWIVEL

3-WAY SLEEVE VALVE

• Provides low cost ON-OFF-EXHAUST operation.

• Slide the sleeve to the ON position. Exhaust ports are closed, valve is open. Reversing the sleeve, opens exhaust ports, shuts off flow.

• Ports covered for protection against exhaust flow.

• Patented body detent secures sleeve ON position.

• Operating pressure to 200 PSI—25° to +200° F.

FOR 5 PSI-PD MULTIPLY x .75

*2 Req’d.
