Foster

Foster FJT Series Coolant Line Disconnects

Type: Straight-Thru, One-Way or Two-Way Valved
Operation: Manual
Working Pressure: 200 PSI
Temperature: -65 - +425F
Features
  • Available in steel or brass
  • Interchange: with DME Jiffy-Tite and Jiffy-Matic and Parker Moldmate Couplers
  • Silicon Tubing Leakproof Seal
  • Two Piece Construction on Straight Stem Sockets
  • Double Knurl on Socket Sleeve for Easier Grip
  • 6-Ball Sockets

Part Number
Body Size
OKCancelClear All
Connection
OKCancelClear All
Thread
OKCancelClear All
Material
OKCancelClear All
NOTES
OKCancelClear All
FP251F
1/4"
FEMALE THREAD
1/8 FPT
Steel
(Available in Brass- Suffix B)
FP252F
1/4"
FEMALE THREAD
1/4 FPT
Steel
(Available in Brass- Suffix B)
FP253F
1/4"
FEMALE THREAD
3/8 FPT
Steel
FP251
1/4"
MALE THREAD
1/8 MPT
Brass
FP252
1/4"
MALE THREAD
1/4 MPT
Brass
(Available in Steel- Suffix S)
FP253
1/4"
MALE THREAD
3/8 MPT
Brass
FP352F
3/8"
FEMALE THREAD
1/4 FPT
Steel
(Available in Brass- Suffix B)
FP353F
3/8"
FEMALE THREAD
3/8 FPT
Steel
(Available in Brass- Suffix B)
FP351
3/8"
MALE THREAD
1/8 MPT
Brass
FP352
3/8"
MALE THREAD
1/4 MPT
Brass
(Available in Steel- Suffix S)
FP353
3/8"
MALE THREAD
3/8 MPT
Brass
FP354
3/8"
MALE THREAD
1/2 MPT
Brass
Part Number
Body Size
OKCancelClear All
Connection
OKCancelClear All
Thread
OKCancelClear All
Material
OKCancelClear All
FP353V
3/8"
MALE THREAD
3/8 MPT
Brass
FP554F
1/2"
FEMALE THREAD
1/2 FPT
Steel
FP556F
1/2"
FEMALE THREAD
3/4 FPT
Steel
FP554
1/2"
MALE THREAD
1/2 MPT
Brass
Part Number
Body Size
OKCancelClear All
Hose Barb Orientation
OKCancelClear All
Hose I.D.
OKCancelClear All
FS204
1/4”
Straight
1/4"
FS205
1/4”
Straight
5/16"
FS206
1/4”
Straight
3/8"
FS224
1/4”
45°
1/4"
FS225
1/4”
45°
5/16"
FS226
1/4”
45°
3/8"
FS214
1/4”
90°
1/4"
FS215
1/4”
90°
5/16"
FS216
1/4”
90°
3/8"
FS306
3/8"
Straight
3/8"
FS308
3/8"
Straight
1/2"
FS326
3/8"
45°
3/8"
FS328
3/8"
45°
1/2"
FS316
3/8"
90°
3/8"
FS318
3/8"
90°
1/2"
FS504
1/2"
Straight
1/2"
FS506
1/2"
Straight
3/4"
FS524
1/2"
45°
1/2"
FS526
1/2"
45°
3/4"
FS514
1/2"
90°
1/2"
FS516
1/2"
90°
3/4"

Clamps must be used with standard hose barbs

Part Number
Body Size
OKCancelClear All
Hose Barb Orientation
OKCancelClear All
Hose I.D.
OKCancelClear All
FS204P
1/4"
Straight
1/4"
FS206P
1/4"
Straight
3/8"
FS224P
1/4"
45°
1/4"
FS226P
1/4"
45°
3/8"
FS214P
1/4"
90°
1/4"
FS216P
1/4"
90°
3/8"
FS306P
3/8"
Straight
3/8"
FS308P
3/8"
Straight
1/2"
FS326P
3/8"
45°
3/8"
FS328P
3/8"
45°
1/2"
FS316P
3/8"
90°
3/8"
FS318P
3/8"
90°
1/2"
FS504P
1/2"
Straight
1/2"
FS524P
1/2"
45°
1/2"
FS514P
1/2"
90°
1/2"

Push on stems do not need clamps

Part Number
Body Size
OKCancelClear All
Hose Barb Orientation
OKCancelClear All
Hose I.D.
OKCancelClear All
FS204V
1/4"
Straight
1/4"
FS205V
1/4"
Straight
5/16"
FS206V
1/4"
Straight
3/8"
FS224V
1/4"
45°
1/4"
FS225V
1/4"
45°
5/16"
FS226V
1/4"
45°
3/8"
FS214V
1/4"
90°
1/4"
FS215V
1/4"
90°
5/16"
FS216V
1/4"
90°
3/8"
FS306V
3/8"
Straight
3/8"
FS308V
3/8"
Straight
1/2"
FS326V
3/8"
45°
3/8"
FS328V
3/8"
45°
1/2"
FS316V
3/8"
90°
3/8"
FS318V
3/8"
90°
1/2"
Part Number
Size
OKCancelClear All
Connection
OKCancelClear All
FS204VP
1/4
1/4” STRAIGHT HOSE STEM
FS206VP
3/8
1/4” STRAIGHT HOSE STEM
FS224VP
1/4
1/4” 45° HOSE STEM
FS226VP
3/8
1/4” 45° HOSE STEM
FS214VP
1/4
1/4” 90° HOSE STEM
FS216VP
3/8
1/4” 90° HOSE STEM
FS306VP
3/8
3/8” STRAIGHT HOSE STEM
FS308VP
1/2
3/8” STRAIGHT HOSE STEM
FS326VP
3/8
3/8” 45° HOSE STEM
FS328VP
1/2
3/8” 45° HOSE STEM
FS316VP
3/8
3/8” 90° HOSE STEM
FS318VP
1/2
3/8” 90° HOSE STEM
Part Number
Size
OKCancelClear All
Thread Type
OKCancelClear All
FS306V2
3/8
3/8” STRAIGHT HOSE STEM
FS308V2
1/2
3/8” STRAIGHT HOSE STEM
FS326V2
3/8
3/8” 45° HOSE STEM
FS328V2
1/2
3/8” 45° HOSE STEM
FS316V2
3/8
3/8” 90° HOSE STEM
FS318V2
1/2
3/8” 90° HOSE STEM
Part Number
Size
OKCancelClear All
Thread Type
OKCancelClear All
FS306VP2
3/8
3/8” STRAIGHT HOSE STEM
FS308VP2
1/2
3/8” STRAIGHT HOSE STEM
FS326VP2
3/8
3/8” 45° HOSE STEM
FS328VP2
1/2
3/8” 45° HOSE STEM
FS316VP2
3/8
3/8” 90° HOSE STEM
FS318VP2
1/2
3/8” 90° HOSE STEM
