Steel SAE 37°JIC 45° Bulkhead Union Elbow

Typical Application: Grease, instrumentation and most hydraulic systems.
Pressure: Refer to the pressure charts above. The maximum working pressure of an adapter is the lower working pressure of the end size. Ex: C3069x8x6, 8 = 4000 psi and 6 = 5000 psi. Maximum working pressure is 4000 psi.
Vibration: Fair resistance.
Temperature Range: –65°F to +400°F.
Material: Carbon Steel – AISI/SAE 12L14, Stainless Steel – type 316 Plating – Zinc, yellow dichromate finish ASTM B633 Type II.
Used With: Brass, bronze and iron pipe.
Advantages:
Dryseal pipe threads (NPTF) (SAE J476), zinc
plate, compact size. Broad range of sizes and styles.

Part Number
TUBE O.D.
OKCancelClear All
M
OKCancelClear All
M1
OKCancelClear All
I
OKCancelClear All
TF5375X4
1/4
.72
1.53
1.11
TF5375X5
5/16
.76
1.53
1.11
TF5375X6
3/8
.83
1.67
1.18
TF5375X8
1/2
.98
1.94
1.38
TF5375X10
5/8
1.11
2.17
1.52
TF5375X12
3/4
1.28
2.44
1.69
TF5375X16
1
1.47
2.56
1.69

(Ref. SAE No. 070801)

Assembly Instructions 1. Tighten approximately 2-1/2 turns past hand tight. 2. Welding procedure: Use electric weldrod AWS-E7018. Recommended procedure specifies using lower amperage than usual and puddling of molten metal to permit gasses created by lead in steel to work through molten lead deposit. Label Set: FS-2000 (adhesive).
