Cable Grip w/o Indicator Light
Cable Grip w/ Indicator Light 24V AC/DC
Cable Grip w/ Indicator Light 110V AC/DC
Plug Connector w/5ft. Cable
54934-05
Conduit Connector
* Includes Connector and Gasket
Air Operator Repair Kit (Except KA6 & KA7)
Solenoid Operator Repair Kit
Spool Assembly for 3-Way Valve
Spool Assembly for 4-Way (2 & 3 position, all ports blocked in center position)
Spool Assembly for 4-Way (3 position, inlet open to cyl. ports in center position)
Spool Assembly for 4-Way (3 position, exhaust open to cyl. ports in center position)
SPECIFICATIONS / TECHNICAL DATA
Voltages:
Standard:
120 VAC: 7 Watts (Optional 3.5 Watts Available)
Optional:
12 VAC: 7 Watts
24 VAC: 7 watts (Optional 3.5 Watts Available)
48 VAC: 7 Watts
240 VAC: 7 Watts
12 VDC: 6 Watts (Optional 2 Watts Available)
24 VDC: 6 Watts (Optional 2 Watts Available)
Duty: Continuous at 90 to 105% of Rated Voltage
Coil Type: Class H Molded w/ 3-Pin Plug-In Connector
Enclosure Classification: NEMA 4 per DIN 40050-IP65
Override: Manual, Non-Locking
Fluids: Filtered Lubricated and Non-Lubricated Compressed Air
Pressure Range:
Internal Pilot Supply: 15 - 150 PSIG
External Pilot Supply: 10" Hg (Vacuum) to 150 PSIG
Air or Manual Operation: 10" Hg (Vacuum) to 150 PSIG
Temperature Range:
Solenoid Valves: -20 to 120 Degrees Fahrenheit
Air and Manual: -20 to 160 Degrees Fahrenheit
Average Flow Factor: Inline Valve, 1.6 Cv
Minimum Pilot
Single Solenoid: 35 PSIG
Double Solenoid, Detent - 25 PSIG
Double Solenoid, Spring Center - 45 PSIG
MATERIALS OF CONSTRUCTION
Body: Aluminum
Spool: Anodized Aluminum
Seals: Nitrile
Solenoid Base: PPS Plastic
Solenoid Plunger and Spring: Stainless Steel
