* Relief Pressure Adjustment Range: 3 - 50 PSIG
* Relief Pressure Adjustment Range: 5-100 PSIG
Mounting Bracket with Panel Nut
Use with Plastic Bonnet
Mounting Bracket with Panel Nut
Use with Brass Bonnet
Panel Mounting Nut
Use with Plastic Bonnet
Panel Mounting Nut
Use with Brass Bonnet
Tamper Resistant Seal Wire
Use with Adjusting Knob
OPTIONS
Change model number as follows:
Factory Set and Locked (Non-Adjustable) Relief Pressure: Use P in the 7th position. and add the following after the model number:
Plastic Bonnet
Locking Method: -R = Wire Seal | Relief Setting: 3 to 100 PSIG
Example:
V06-121-PNKA-R075:
Locking Method: Wire Seal
Relief Pressure Setting: 75 PSIG
Brass Bonnet
Locking Method: -K = Lock Nut | Relief Setting: 3 to 100 PSIG
Example:
V06-122-PNAA-K005:
Locking method: Lock Nut
Relief Pressure Setting: 5 PSIG
Relief Valve w/ Gauge: Use G in the 8th position.
SPECIFICATIONS
Fluid: Water or Compressed Air
Temperature Range:
Plastic Bonnet: 35 to 150 Degrees Fahrenheit
Brass Bonnet: 35 to 175 Degrees Fahrenheit
Gauge Ports: 1/8 PTF
MATERIALS OF CONSTRUCTION
Body: Brass
Bonnet: Acetal or Brass
Valve Seat: PPO Plastic
Diaphragm: Nitrile
